192-0836 Oil Pressure Switch For Skid Steer Loader 216 216B 216B3 226 226B 226B3 228 232 232B 236 236B 236B3 242 242B 242B3
- Alternative (cross code) number:CA1920836 192-0836 1920836
- Caterpillar 1920836 SWITCH GP-PRESSURE
- Weight: 0.18 pounds
Description
192-0836 Oil Pressure Switch For Skid Steer Loader 216 216B 216B3 226 226B 226B3 228 232 232B 236 236B 236B3 242 242B 242B3
Attributes:
• Switch assembly with O-ring and pigtail connector
• Contact Position: Normally open
• Medium: Oil, fuel, air
• Actuation Pressure: 517 kPa (75 psi)
• Thread Size: 9/16-18
• Connector Type: 2 Pin DT
• Versatile solution for pressure control
• Provides high level of safety
• Extends equipment life
• Designed to work in unison with the rest of your Cat components to ensure maximum potential of your equipment.
SPECIFICATIONS FOR PART NUMBER 192-0836
1. Overall Length (mm): 309.4
2. Wire Length (mm): 200
3. Hex Size (mm): 30.2
4. Connector Type: 2 Pin DT
192-0836 Part Number on catalog scheme: 5
